Arctic Cat 1100 Turbo, Suzuki Z1 1100 Turbo, ATV, UTV, Watercraft

Arctic Cat X1100 Turbo, XF1100 Turbo, M1100, Turbo, 2012-16 Suzuki Z1, 1100t, Kawasaki

• Varied Flow Rates include:
  350cc 450cc 550cc 650cc 750cc 830cc 1000cc & 1400cc :

  From the drop-down menus choose your flow rate and connector type.

Specifications: Compact EV-14-style fuel injector - Made in USA
Overall length: 55 mm
Nozzle length: 9.5 mm
Nozzle diameter: 8.2 mm
O-ring to seal: 44 mm (center to bottom seal surface).
Overall diameter: 15.5 mm
Fuel rail o-ring: 12 mm
Intake seal: 16 mm

Functional Specifications:

• Injectors are compatible with all gasoline and oxygenated fuels; E85, etc.

• High resistance coil -12.5 Ohms

• Excellent spray pattern and superior fuel atomization
• Easy to tune with consistent fuel delivery at idle, cruise, and at high RPM

Coil Resistance: 12.5 Ohms
Voltage: 8-18 Volts, Nominal 13.5 Volts
