Bosch EV-14; Arctic Cat, Kymco, Yamaha
FiveoMotorsport / Bosch
Part Number:
233Y; 040Y
Resistance:
12.5 Ohms
Connector Type:
USCAR (EV6)
High Performance
$80.00 (USD)
-
All fuel injectors include a flow data chart for your individually tested and balanced fuel injectors.
-
Use for: Arctic Cat, Kymco
- Prices listed are for a single injector - See photos.
Dimensional Specifications:
Overall length: 55 mm
Nozzle length: 9.5 mm
Nozzle diameter: 8.2 mm
O-ring to seal: 44 mm (center to bottom seal surface).
Overall body diameter: 13.5 mm
Fuel rail o-ring: 12.0 mm
Intake seal: 16.0 mm
Functional Specifications:
-
Injectors are compatible with all gasoline, oxygenated fuels, ethanol, E85
-
Coil Resistance: 12.5 Ohms
-
Excellent spray pattern and superior fuel atomization
-
Easy to tune with consistent fuel delivery at idle, cruise, and at high RPM
Electrical Connector: U.S. CAR/EV-14;EV14EK
Coil Resistance: 12.5 Ohms
Voltage: 8-15 Volts, Nominal 13.5 Volts
Pressure: Min. 36 PSI (2.5 bar), Max. 145 PSI (10 BAR)
Manufacturer | FiveoMotorsport / Bosch |
---|---|
OEM or Aftermarket | High Performance |
Connector Type | USCAR (EV6) |
Impedance | 12.5 Ohms |
Part Number | 233Y; 040Y |
Year(s) | 2016 |
