Fuel Injector: Custom Fiveo 233US / 13mm Seal: Arctic Cat Thundercat, 180hp 3-Cyl

Fiveomotorsport is in the business of providing excellent customer satisfaction. If you cannot find the product you're looking for, contact us and we will do our best to source it for you.

Part No: 233US / 13mm Seal: Arctic Cat Thundercat, 180hp 3-Cyl
Notes / Specifications:

LIST PRICE Includes: One (1) FUEL INJECTOR and One (1) USCAR/Keihin Connector Adapter233US / 13mm Seal: Arctic Cat Thundercat, 180hp 3-Cyl - Stock flow rate: 400cc (approximately) Will handle maximum 185 horsepower, naturally aspirated.
Read More

Qty:
Quantity
Price:
$ USD


Still not sure which injectors are right for you?  Let us help guide you in your selection process.  Click here to learn more.

Excellent customer service and support can be found here or email contact@fiveomotorsport.com or call 1.562.867.4999.

Warranty and return policy information can be found here.

Video

Video Description:
Upload Date:
View Count:
FiveO's Youtube Channel:
  Part No. Notes / Specifications Qty / Price

233US / 13mm Seal: Arctic Cat Thundercat, 180hp 3-Cyl

LIST PRICE Includes: One (1) FUEL INJECTOR and One (1) USCAR/Keihin Connector Adapter

233US / 13mm Seal: Arctic Cat Thundercat, 180hp 3-Cyl -
Stock flow rate: 400cc (approximately) Will handle maximum 185 horsepower, naturally aspirated.
450cc: Max 207 hp, naturally aspirated
530cc: Max 242 hp, naturally aspirated
630cc: Max 240 hp, Turbocharged
750cc: Max 284 hp, Turbocharged
830cc: Max 315 hp, Turbocharged

Over 315 horsepower - Call for fuel injector flow rate specifications.

All Sets Ready to install - Plug 'n' Play!

  • Get the latest in fuel injector technology with this custom EV14 injector--fast pulse rates, superior fuel atomization, and easy tuning.
  • All o-rings/seals supplied for installation.
  • Watch our Pulse Test video.

FLOW CHART: (See sample chart photo). Each set is sold with a complete flow-data chart indicating individual dynamic and static flow rates at 3.0, 3.5, and 4.0 BAR at 15%, 50% and 100% for each injector, along with complete dead time (latency) table. Flow matching was done with industry-standard equipment of the highest quality.
The tests were performed at varying temperatures to achieve realistic results. Linear tuning with excellent low-end, and idle rpm.
Individual sets may flow differently than this set.
But no set will ever vary more than +/- 0.5-0.75%

You don't get this kind of technology from an OE injector.

Indisputable facts about Fiveomotorsport fuel injectors:
Fiveo offers custom, balanced and flow-matched EV14 fuel injectors that we guarantee to dynamically flow a true 530cc/50lbs.
Fiveo EV14 injectors are delivered with custom, individual flow-sheets. Each injector Fiveo sells is inscribed with a control number.
Those control numbers are shown on the flow sheet that is sent to you with your set.
Final word: We deliver a solid, dependable, easy to tune product.

This is a high performance, high volume fuel injector.
The fuel delivery is from a single-hole, modified disc with difuser plate that delivers a medium-wide cone-shape spray pattern for maximum fuel atomization.

Body Design: Composite plastic, black
Injector type: Top feed, saturated

Sample dead time (latency): 530cc - 0.780ms at 14 volts (Complete table included with each set).
Overall Length: 2.0 inches, 50 mm.  O-ring to O-ring length:  1.5 inches, 37 mm.
Body Diameter: 0.63 inches, 16 mm
O-rings: Viton, upper o-ring is 14.5 mm diameter, lower seal is 13.0 mm diameter
Resistance: 12.5 Ohms
Electrical connector type: USCAR

Item Condition:

All of the Fiveomotorsport fuel injectors are shipped in brand-new condition unless otherwise stated as reconditioned or take-out injectors. All fuel injectors are covered by our warranty outlined below, unless otherwise stated. Fiveo's Exclusive Warranty:
We stand behind all of our products with our 36 month/unlimited miles warranty. If you are not 100% satisfied, we will refund your purchase price for returned unused fuel injectors in their original packaging, minus shipping costs and up to a 15% restocking fee. If you ever have an injector go outside specification or fail for any reason when functioning within the stated operating conditions, we will replace it with a brand new fuel injector. You pay only the shipping costs. (Some racing applications may void this warranty).

Shipping and Handling Time:

All orders received by 2pm PST Monday-Friday will ship the same day. Orders received after 2pm on Friday will ship the following Monday. Average delivery times are listed below:

USPS priority mail – 3 business days

USPS Express International – 5-8 business days

FedEx Overnight

FedEx 2-Day
